FLEXON UL STYLE – 20276 WIRES & CABLES
FLEXON UL STYLE – 20276 WIRES & CABLES
Application : Used as multi conductor cable for internal wiring of electrical and electronics equipments and electric products.
Feature :
- PVC insulation.
- Rated voltage 30 V ac; rated temperature 80˚c
- Withstands the flame test UL VW-1 and FT1.
- Flame retardant
- Resistance to oils, acids, solvents, and fungus.
- Optional shield, covering, or braid
| Style | Diameter of cable under jacket | Minimum Average Thickness | Minimum Thickness at any point |
| Min | Min | Min | |
| UL 20276 | ≥8.59 | 0.508 | 0.43 |
| UL 20276 | 8.60≤ ≥17.78 | 0.762 | 0.609 |
| UL 20276 | 17.80≤ ≥25.4 | 1.520 | 1.219 |
| UL 20276 | 38.2≤ ≥63.5 | 2.030 | 1.625 |
