FLEXON UL STYLE – 2129 WIRES & CABLES
FLEXON UL STYLE – 2129 WIRES & CABLES
Application : these cable are used for internal wiring of panels and electrical equipment. These are used as connection wire in machines laid in protective tubes and flexible pipes and also for motors and transformers.
Feature :
- PVC insulation.
- Rated voltage 600 V ac or 1000 V rated temperature 105˚C
- Withstands the flame test UL VW-1 and FT1 heat and damp resistant.
- Resistant to oils, solvents, acids and alkalics
- Optional shield, covering and braid
| Style | Conductor | Insulation | Standard | ||
| Nominal Size | Approx Outer Diameter | Conductor Resistance at 20°c | |||
| mm² | AWG | mm | (Ω/km) | ||
| UL 2129 | 0.202 | 24 | 2.2 | 87.6 | UL 758 UL 1581 |
| UL 2129 | 0.32 | 22 | 2.3 | 55.4 | |
| UL 2129 | 0.52 | 20 | 2.6 | 34.6 | |
| UL 2129 | 0.82 | 18 | 2.85 | 21.8 | |
| UL 2129 | 1.31 | 16 | 3.1 | 13.7 | |
| UL 2129 | 2.08 | 14 | 3.50 | 8.62 | |
| UL 2129 | 3.30 | 22 | 4.00 | 5.43 | |
| UL 2129 | 5.26 | 10 | 4.7 | 3.401 | |
| Style | Diameter of cable under jacket | Minimum Average Thickness | Minimum Thickness at any point |
| Min | Min | Min | |
| UL 2129 | 17.79≤ ≥25.4 | 1.140 | 0.914 |
| UL 2129 | 25.5≤ ≥38.1 | 1.520 | 1.219 |
| UL 2129 | 38.2≤ ≥114.3 | 2.030 | 1.625 |
